AR_MIX

    Our AR_MIX mixers can be used practically in all sort of industrial sectors, where is needed a production of compounds beginning from other compounds more elemental, to summarize:

• Dry products mix (powders, pellets, fibres, …).
• Dry and liquid products mix (greases, additives, …).
• Liquid and pasted products mix.
• Aeration of products.
• Mechanical fluidification of powder products.
• Process reaction.

WORKING:

AR_MIX mixers are the fruit obtained through a long time of experience making and installing mixing machines in all sort of industrial sectors.

AR_MIX mixers work up the mechanical fluidification set of mixing products. Just to do it, rotating arrows are used inside of the mixing chamber, which brings about a tridimensional projection of the particles of elements to homogenize.

When the mixing process is rated can be equipped the mixing picker of elements machine, which help to obtain a perfect homogenized mix, also in constituents of different density and granulometrics.

The mix quality is so high that are obtained mixings of elements about rates of 1:10000.



GENERAL CHARACTERISTICS:

Taking into account the product that we want to mix are chosen different materials for the mixing chamber's construction. Carbon steel, stainless steel, special laps, …

Characteristics:

• Cylindered mixing chamber.
• Mixing elements based on arrows, with half-arrows and lateral scrapers.
• Inlet valves, according to the needs.
• Survey gates with a safety integrated system.
• Outlet valve, through throttle or whole aperture with two gates in V.
• Motor driver with transmission by belts and planetary reducer. Safety fuse .
• External bearings, with a labyrinth seal system and a pressurized system with compressed air.
• A protector for the transmission.
• Exhaust system integrated in the machine.
• Support frame for the tie line with discharging hoppers, which reduce the height of the whole plant.
